Ø  Ultra-thin: The thickness of the cabinet is 66mm, which is very thin and suitable for all kinds of installation places.



Ø Ultra-light: The screen is the lightest, and the weight of the single box is around 3.8 KG.



Ø Unique heat dissipation design: all-aluminum structure, circuit optimization and energy-saving design, heat dissipation through the whole body, almost no heat in the hand touch, silent operation and no fan.



Ø High-precision unit connection process: independent research and development, self-opening, CNC machining, process error compensation technology, the unit is perfectly docked, and the seam is not visible on the front.



Ø High-precision bottom shell design: high-precision milling machine processing, plus special design splicing parts, to solve the problem of flatness that may occur between module and aluminum plate structure, easy to operate, easy to install and maintain



SPECIFICATION:

Item	P1.667
Pixel pitch	1.667mm
Lamp	SMD1010
Pixel DensityDots/m2	360000
Module size	200mm*150mm
Scan mode	1/30scan
Brightness	≥800nits
Cabinet size	400mm*300mm
IP Rate	IP40
Color Temperature	3200K -9300/Adjustable
View Angle H /V	120degree - 180degree
Signal Processing	10 bits or 16bits
Gray Processing	4096*4096*4096      16834*16834*16834     65536*65536*65536
Control Distance	CAT5 cable< 100m ,Multimode optic fiber < 500m,Singlemode optic fiber >2KM
Refresh Rate	>800HZ
Working Temperature	Working Temperature : -20℃ -40℃，Storge Temperature :-20℃ -60℃
M2 Power consumption (MAX)	<1200W
M2 Power consumption(AVE)	<600W
